• Supports up to 8 x double slot GPU cards
• 3rd Gen. Intel® Xeon® Scalable Processors
• 8-Channel RDIMM/LRDIMM DDR4 per processor, 24 x DIMMs
• Dual ROM technology supported
• 2 x 10Gb/s BASE-T LAN ports (Intel® X710-AT2)
• 1 x Dedicated management port
• 4 x 2.5" SATA/SAS hot-swappable HDD/SSD bays
• 4 x 2.5" SATA/SAS/Gen4 NVMe hot-swappable HDD/SSD bays
• 2 x PCIe x16 Half-length low-profile slots for add-on cards
• Aspeed® AST2600 management controller
• Dual 3200W 80 PLUS Platinum hot-swap power supply


2U (W438 x H87.5 x D820 mm)
MZ12-HD3 Rev. 3.0
AMD EPYCTM 7003 Series processors
Single processor, 7nm technology, cTDP up to 280W
Up to 64-core, 128 threads per processor
Compatible with AMD EPYCTM 7002 Series processors
Socket SP3
System on Chip
8-Channel DDR4 memory, 8 x DIMM slots
RDIMM/LRDIMM modules up to 128GB supported
Memory speed: Up to 3200 MHz
1 x 10/100/1000 management LAN
Integrated with Aspeed®AST2500
2D Video Graphic Adapter with PCIe bus interface
1920x1200@60Hz 32bpp, DDR4 SDRAM
Front: 4 x 3.5" SATA hot-swap HDD/SSD bays
- 2.5" HDD/SSD supported; SATA devices supported only
Rear: 2 x 2.5" Gen4 U.2/SAS/SATA hybrid hot-swap SSD bays
Depending on SAS Card
Expansion Slots
4 x PCIe x16 slots (Gen4 x16) for GPU cards Slots
1 x PCIe x16 slot (Gen4 x16 or x8), FHHL
1 x PCIe x8 slots (Gen4 x0 or x8), FHHL
1 x OCP 3.0 Gen4 x16 mezzanine slot
Internal I/O
1 x TPM header, 1 x Front panel header
Front I/O
1 x USB 3.0
Rear I/O
2 x USB 3.0, 1 x VGA, 1 x MLAN
Backplane I/O
Front side_CBPG041: 4 x SATA/SAS ports
Rear side_CBP2021: 2 x NVMe/SATA/SAS ports
Speed and bandwidth: SATA 6Gb/s, SAS 12Gb/s or PCIe x4
1 x TPM header with SPI interface
Optional TPM2.0 kit: CTM010
Power Supply
Dual 1600W 80 PLUS Platinum redundant power supply
System Management
Aspeed® AST2500 management controller
Management AccelStor Management Console (AMI MegaRAC SP-X)
OS Compatibility
Windows Server 2016 / 2019
RHEL 8.3 ( x64) or later
SLES 12 SP5 ( x64) / 15 SP2 ( x64) or later
Ubuntu 18.04.5 LTS (x64) / 20.04 LTS (x64) or later
VMware ESXi 6.7 Update3 P03 / 7.0 Update1 or later
Citrix Hypervisor 8.2.0 or later
Net Weight: 18.5 kg / Gross Weight: 29 kg
System Fans
5 x 80x80x38mm (16,300rpm)
Operating Properties
Operating temperature: 10°C to 35°C
Operating humidity: 8-80% (non-condensing)
Non-operating temperature: -40°C to 60°C
Non-operating humidity: 20%-95% (non-condensing)
Packaging Content
1 x GS240-10
1 x CPU heatsink 1 x Rail kit
